The Two Post Hydraulic Lift 10,000lbs is a robust lifting solution designed for heavy-duty vehicle maintenance, featuring a 10,000-pound capacity and a reliable hydraulic system for safe and efficient lifting.
*The lift must be installed on a level concrete floor, having a minimum thickness of 30cm and an extension of at least 1.5m from anchoring points. The lift installation concrete surface must be perfectly smooth.
Specifications
| Net Weight | 1245.6 lbs |
| Lifting Capacity | 10000lbs |
| Hydraulic Pressure | 20MPa |
| Max. Lifting Height | 74.8" |
| Min. Height | 4.1" |
| Height Overall | 111.1" |
| Support Arm Reach | 31.5"-47.2" |
| Inside Column | 110.2" |
| Drive-through Clearance Max. | 98.2" |
| Anchoring | M19x140 |
| Concrete Grade Min. | C20/25(DIN 1045:2001-07) |
| Motor Power | 2.2KW |
| Rated Current | 14.6A |
| Fuse Protection | 16 A time delay |
| Power Supply | 220V/380V 50HZ |
| Sound Pressure Level | ≤75dB(A) |
Package Size
- Main Box Dimension:113.8"x19.7"x29.2"
- Main Box Weight (lb): 1146.4
- A forklift or equivalent is required for unloading.
